Q103

10.1 Inch android industrial Tablet for enterprise users

IP67 protect + 1.2M Drop | Durable display with Gorilla glass III | Octa core 2.0Ghz

● Android 10 customizable OS ( Windows optional )

● Rugged: IP68 rated, and 1.2 m drop

● Long-lasting embedded 10000mAh battery

● Support 4G,Bluetooth , Wi-Fi

● Thin & lightweight design for easy portability

● Cradle and hand strap for customer needs


Function

Android 11
Android 11
IP68
IP68
8/10 inch Display
8/10 inch Display
4G LTE
4G LTE
QR-code Scanner
QR-code Scanner
NFC
NFC
High-Capacity Battery
High-Capacity Battery
RFID
RFID
GPS
GPS
Transportation&logistic
Transportation&logistic

Product Detail

Technical Data

Application

Product Tags

Introduction

The Q103 offers the perfect balance between handiness, performance and stability to survive in the industrial working condition. With a compact size of 291.4*178.8*17mm, the rugged mini tablet is comfortable to use and fits well into the hand. A maximum net weight of 950g and an included carrying strap tremendously simplify the devices’ transportation.

Equipped with Intel® Atom™ x5-Z8350 (Cherry Trail) processor provides the enough performance to run multimedia applications smoothly and without interference. Alternatively, the rugged tablet is also available with MTK6771 octa core, 2.0 GHz CPU. Additionally, with a battery capacity of maximum 10000 mAh, nothing stands in the way of a successful workday.

Despite all its flexibility, the Hosoton 10.1 inch panel pc is primarily a rugged tablet and a corresponding IP68 rate and comply with MIL-STD-810G stands are part of the durable equipment withstanding drops or operation in hostile environments.

IP67 rate ensure the reliability in different scenarios

Damage and scratch ,corning Gorilla glass provide a extra layer of protection to Q103 .The capacitive touch panel supports operation with multi-touch, wet fingers or gloved hands.

Stable wireless Connectivity for outdoor operation

Q103-Rugged-IP67-Android-tablet-pc_08
Q103-Rugged-IP67-Android-tablet-pc_09

Professional infrared barcode scanning

Q103 adopts state-of-the-art infrared barcode scan engine including that of Zebra and honeywell, which enable lightning-fast capture of the 1D/2D bar codes, even those dirty, wrinkled and poorly-printed codes, its wide scan range and work distance bestow flexibility and reliability in various applications. Whether the goods at hand or farther rack, you will get satisfying result with a easily quick sweep.

NFC available for card reader writer

Q103 NFC reader function supports ISO/IEC 18092 and ISO/IEC 21481 protocols near-filed communication and data transmission. It is high security, fast and stable connectivity, and low power consumption meet the requirements in user ID card authentication and e-payment.

Q103-Rugged-IP67-Android-tablet-pc_10
Q103-Rugged-IP67-Android-tablet-pc_11

Fingerprint recognition

Optical /Capacitive fingerprint scanner to adapt all kinds of industry requirements. Come with a superior fingerprint scanner, which allow to collect and verify the fingerprint with high efficiency. It captures high quality fingerprint images ,even operated with wet fingers or in strong light, and could convert the image to ISO data format then submit it to the database of the server

Powerful battery for long-time working

Long-lasting performance 10000mAh battery rechargeable Li-ion battery allow you fulfill a whole working day easily. It will never to be a issue to worry your business will be interrupted by power off.

Q103-Rugged-IP67-Android-tablet-pc_01

  • Previous:
  • Next:

  • Operation System
    OS Android 10
    GMS certified Support
    CPU 2.0 Ghz,MTK6762 processor Octa-Core
    Memory 4 GB RAM / 64 GB Flash (6+128GB optional)
    Languages support English, Simplified Chinese, Traditional Chinese, Japanese,Spanish, German, French, Italian, Portuguese, Korean and multiple languages
    Hardware specification
    Screen Size 10.1 inch color 1920 x 1200 display,up to 600 nits
    Touch Panel Gorilla glass III with 5 points Capacitive Touch Screen
    Buttons / Keypad 8 Function Keys: Power key, volume +/-, return key, 4 custom key
    Camera Front 5 megapixels, rear 13 megapixels, with flash and auto focus function
    Indicator Type LED, Speaker, Vibrator
    Battery Rechargeable li-ion polymer, 10000mAh
    Symbologies
    HF RFID Support HF/NFC Frequency 13.56MhzSupport: ISO 14443A&15693, NFC-IP1, NFC-IP2
    Bar code scanner Optional
    Fingerprint scanner Optional
    UHF Optional
    Infrared dual cameras recognition Optional
    IRIS recognition Optional
    Infrared thermal imaging  Optional
    Communication
    Bluetooth® Bluetooth®4.2
    WLAN Wireless LAN 802.11a/b/g/n/ac, 2.4GHz and 5GHz Dual Frequency
    WWAN GSM: 850,900,1800,1900 MHzWCDMA: 850/1900/2100MHzLTE:FDD-LTE (B1/B2/B3/B4/B5/B7/B8/B12/B17/B20)TDD-LTE (B38/B39/B40/B41)
    GPS GPS/BDS/Glonass, error range ± 5m
    I/O Interfaces
    USB USB TYPE-C*1 ,USB TYPE-A*1
    POGO PIN PogoPin bottom: Charging via cradle
    SIM Slot Single SIM Slot
    Expansion Slot MicroSD, up to 256 GB
    Audio One speaker with Smart PA (95±3dB @ 10cm), One receiver, Dual noise-cancelling microphones
    RJ 45 Optional
    HDMI Optional
    CAN BUS Optional
    Enclosure
    Dimensions ( W x H x D ) 291.4*178.8*17mm
    Weight 950g (with battery)
    Durability
    Drop Specification 1.2m, 1.5m with boot case ,MIL-STD 810G
    Sealing IP67
    Environmental
    Operating temperature -20°C to 50°C
    Storage temperature - 20°C to 70°C (without battery)
    Charging temperature 0°C to 45°C
    Relative Humidity 5% ~ 95% (Non-Condensing)
    What comes in the box
    The standard package contents Q103 DeviceUSB Cable (Type C)Adaptor (Europe)
    Optional Accessory Hand StrapCharging dockingVehicle cradle

    It is perfect solution for outdoors workers under harsh working environment. Widely used in Hazardous Field, intelligent agriculture, military, logistics industry etc.
